GALAXY - IV
Rock
EVA пленка для триплекса
Подача станка: Механическая/Ручная
Обрабатываемый материал: Панели ламинированные ДСП/МДФ/Фанера с меламиновым или пластиковым покрытием.
Тип станков: Пильные центры с ЧПУ и подрезным узлом
Форма зуба: прямой трапециевидный
| D, mm | B, mm | b, mm | d, mm | Z | Назначение | Код пилы | Код пилы |
| 300 | 4,4 | 3,0 | 30 | 60 | Panhans | LSB30001 | |
| 300 | 4,4 | 3,0 | 65 | 60 | Selco | LSB30002 | |
| 300 | 4,4 | 3,0 | 75 | 60 | Homag | LSB30003 | |
| 300 | 4,4 | 3,0 | 80 | 60 | SCM | LSB30004 | |
| 300 | 4,4 | 3,0 | 30 | 72 | Panhans | LSB30005 | |
| 300 | 4,4 | 3,0 | 65 | 72 | Selco | LSB30006 | |
| 300 | 4,4 | 3,0 | 75 | 72 | Homag | LSB30007 | |
| 300 | 4,4 | 3,0 | 80 | 72 | SCM | LSB30008 | |
| 305 | 4,4 | 3,0 | 30 | 60 | Mayer, Panhans, SCM | LSB30501 | |
| 320 | 4,4 | 3,0 | 65 | 72 | Selco | LSB32001 | |
| 320 | 4,4 | 3,0 | 75 | 72 | Giben | LSB32002 | |
| 350 | 4,4 | 3,0 | 30 | 54 | Panhans, Scheer | LSB35001 | LSB35001R |
| 350 | 4,4 | 3,0 | 60 | 54 | Holzma | LSB35002 | LSB35002R |
| 350 | 4,4 | 3,0 | 30 | 72 | Panhans, Scheer | LSB35003 | LSB35003R |
| 350 | 4,4 | 3,0 | 50 | 72 | Giben | LSB35006 | LSB35006R |
| 350 | 4,4 | 3,0 | 60 | 72 | Holzma | LSB35004 | LSB35004R |
| 350 | 4,4 | 3,0 | 80 | 72 | Gabbiani, Mantec | LSB35005 | LSB35005R |
| 355 | 4,4 | 3,0 | 30 | 54 | Panhans, SCM | LSB35501 | LSB35501R |
| 355 | 4,4 | 3,0 | 75 | 54 | Giben | LSB35502 | LSB35502R |
| 355 | 4,4 | 3,0 | 80 | 54 | Gabbiani, Mantec | LSB35503 | LSB35503R |
| 355 | 4,4 | 3,0 | 30 | 72 | Panhans, SCM | LSB35504 | LSB35504R |
| 355 | 4,4 | 3,0 | 75 | 72 | Giben | LSB35505 | LSB35505R |
| 355 | 4,4 | 3,0 | 80 | 72 | Gabbiani, Mantec | LSB35506 | LSB35506R |
| 360 | 4,4 | 3,0 | 65 | 60 | Selco | LSB36001 | LSB36001R |
| 360 | 4,4 | 3,0 | 65 | 72 | Selco | LSB36002 | LSB36002R |
| 380 | 4,4 | 3,0 | 50 | 48 | Giben | LSB38006 | LSB38006R |
| 380 | 4,4 | 3,0 | 80 | 48 | Gabbiani | LSB38009 | LSB38009R |
| 380 | 4,4 | 3,0 | 50 | 60 | Giben | LSB38007 | LSB38007R |
| 380 | 4,4 | 3,0 | 60 | 60 | Holzma | LSB38001 | LSB38001R |
| 380 | 4,4 | 3,0 | 30 | 72 | LSB38011 | LSB38011R | |
| 380 | 4,4 | 3,0 | 50 | 72 | Giben | LSB38008 | LSB38008R |
| 380 | 4,4 | 3,0 | 60 | 72 | Holzma | LSB38002 | LSB38002R |
| 380 | 4,4 | 3,0 | 80 | 72 | Gabbiani | LSB38010 | LSB38010R |
| 380 | 4,8 | 3,5 | 60 | 60 | Holzma | LSB38003 | LSB38003R |
| 380 | 4,8 | 3,5 | 60 | 72 | Holzma | LSB38004 | LSB38004R |
| 380 | 4,8 | 3,5 | 60 | 84 | Holzma | LSB38005 | LSB38005R |
| 400 | 4,4 | 3,0 | 30 | 48 | LSB40001 | LSB40001R | |
| 400 | 4,4 | 3,0 | 75 | 48 | Giben | LSB40002 | LSB40002R |
| 400 | 4,4 | 3,0 | 80 | 48 | Selco | LSB40003 | LSB40003R |
| 400 | 4,4 | 3,0 | 80 | 48 | Gabbiani | LSB40010 | LSB40010R |
| 400 | 4,4 | 3,0 | 30 | 60 | LSB40004 | LSB40004R | |
| 400 | 4,4 | 3,0 | 75 | 60 | Giben | LSB40005 | LSB40005R |
| 400 | 4,4 | 3,0 | 80 | 60 | Selco | LSB40006 | LSB40006R |
| 400 | 4,4 | 3,0 | 80 | 60 | Gabbiani | LSB40011 | LSB40011R |
| 400 | 4,4 | 3,0 | 30 | 72 | Scheer | LSB40007 | LSB40007R |
| 400 | 4,8 | 3,5 | 60 | 72 | Holzma | LSB40013 | |
| 400 | 4,4 | 3,0 | 75 | 72 | Giben | LSB40008 | LSB40008R |
| 400 | 4,4 | 3,0 | 80 | 72 | Selco | LSB40009 | LSB40009R |
| 400 | 4,4 | 3,0 | 80 | 72 | Gabbiani | LSB40012 | LSB40012R |
| 420 | 4,8 | 3,5 | 60 | 60 | Holzma | LSB42001 | LSB42001R |
| 420 | 4,8 | 3,5 | 60 | 84 | Holzma | LSB42002 | LSB42002R |
| 430 | 4,4 | 3,0 | 30 | 48 | LSB43001 | LSB43001R | |
| 430 | 4,4 | 3,0 | 75 | 48 | Giben | LSB43002 | LSB43002R |
| 430 | 4,4 | 3,0 | 80 | 48 | Selco - Gabbiani | LSB43003 | LSB43003R |
| 430 | 4,4 | 3,0 | 30 | 60 | LSB43004 | LSB43004R | |
| 430 | 4,4 | 3,0 | 75 | 60 | Giben | LSB43005 | LSB43005R |
| 430 | 4,4 | 3,0 | 80 | 60 | Selco - Gabbiani | LSB43006 | LSB43006R |
| 430 | 4,4 | 3,0 | 30 | 72 | LSB43007 | LSB43007R | |
| 430 | 4,4 | 3,0 | 75 | 72 | Giben | LSB43008 | LSB43008R |
| 430 | 4,4 | 3,0 | 80 | 72 | Selco - Gabbiani | LSB43009 | LSB43009R |
| 430 | 4,4 | 3,0 | 75 | 96 | Giben Prismatic | LSB43010 | LSB43010R |
| 450 | 4,4 | 3,0 | 30 | 48 | Mayer, Panhans, Schelling | LSB45001 | LSB45001R |
| 450 | 4,4 | 3,0 | 60 | 48 | Holzma | LSB45002 | LSB45002R |
| 450 | 4,4 | 3,0 | 80 | 48 | Selco - Gabbiani | LSB45003 | LSB45003R |
| 450 | 4,4 | 3,0 | 30 | 60 | Mayer, Panhans, Schelling | LSB45004 | LSB45004R |
| 450 | 4,4 | 3,0 | 60 | 60 | Holzma | LSB45005 | LSB45005R |
| 450 | 4,4 | 3,0 | 80 | 60 | Selco - Gabbiani | LSB45006 | LSB45006R |
| 450 | 4,4 | 3,0 | 30 | 72 | Mayer, Panhans, Schelling | LSB45007 | LSB45007R |
| 450 | 4,4 | 3,0 | 60 | 72 | Holzma | LSB45008 | LSB45008R |
| 450 | 4,4 | 3,0 | 80 | 72 | Selco - Gabbiani | LSB45009 | LSB45009R |
| 450 | 4,8 | 3,5 | 30 | 48 | Mayer, Panhans, Schelling | LSB45010 | LSB45010R |
| 450 | 4,8 | 3,5 | 60 | 48 | Holzma | LSB45011 | LSB45011R |
| 450 | 4,8 | 3,5 | 80 | 48 | Selco | LSB45012 | LSB45012R |
| 450 | 4,8 | 3,5 | 30 | 60 | Scheer | LSB45013 | LSB45013R |
| 450 | 4,8 | 3,5 | 60 | 60 | Holzma | LSB45014 | LSB45014R |
| 450 | 4,8 | 3,5 | 80 | 60 | Selco | LSB45015 | LSB45015R |
| 450 | 4,8 | 3,5 | 30 | 72 | Scheer | LSB45016 | LSB45016R |
| 450 | 4,8 | 3,5 | 60 | 72 | Holzma | LSB45017 | LSB45017R |
| 450 | 4,8 | 3,5 | 80 | 72 | Selco | LSB45018 | LSB45018R |
| 460 | 4,4 | 3,2 | 30 | 72 | Schelling | LSB46001 | LSB46001R |
| 470 | 4,4 | 3,2 | 75 | 48 | Giben | LSB47001 | LSB47001R |
| 470 | 4,4 | 3,2 | 75 | 60 | Giben | LSB47002 | LSB47002R |
| 470 | 4,4 | 3,2 | 75 | 72 | Giben | LSB47003 | LSB47003R |
| 470 | 4,4 | 3,2 | 75 | 96 | Giben | LSB47004 | |
| 480 | 4,8 | 3,5 | 80 | 48 | Mantec* | LSB48002 | LSB48002R |
| 480 | 4,8 | 3,5 | 80 | 60 | Mantec* | LSB48003 | LSB48003R |
| 480 | 4,8 | 3,5 | 30 | 72 | Schelling | LSB48004 | LSB48004R |
| 480 | 4,8 | 3,5 | 80 | 72 | Mantec* | LSB48001 | LSB48001R |
| 500 | 4,4 | 3,2 | 30 | 48 | Schelling | LSB50001 | LSB50001R |
| 500 | 4,4 | 3,2 | 80 | 48 | Gabbiani | LSB50002 | LSB50002R |
| 500 | 4,4 | 3,2 | 30 | 60 | Schelling | LSB50003 | LSB50003R |
| 500 | 4,4 | 3,2 | 80 | 60 | Gabbiani | LSB50004 | LSB50004R |
| 500 | 4,4 | 3,2 | 30 | 72 | Schelling | LSB50005 | LSB50005R |
| 500 | 4,8 | 3,5 | 30 | 48 | Schelling | LSB50006 | LSB50006R |
| 500 | 4,8 | 3,5 | 60 | 48 | Holzma | LSB50007 | LSB50007R |
| 500 | 4,8 | 3,5 | 75 | 48 | Giben | LSB50008 | LSB50008R |
| 500 | 4,8 | 3,5 | 60 | 60 | Holzma | LSB50009 | LSB50009R |
| 500 | 4,8 | 3,5 | 75 | 60 | Giben | LSB50010 | LSB50010R |
| 500 | 4,8 | 3,5 | 60 | 72 | Holzma | LSB50011 | LSB50011R |
| 500 | 4,8 | 3,5 | 75 | 72 | Giben | LSB50012 | LSB50012R |
| 520 | 4,8 | 3,5 | 60 | 48 | Holzma | LSB52001 | LSB52001R |
| 520 | 4,8 | 3,5 | 60 | 60 | Holzma | LSB52002 | LSB52002R |
| 520 | 4,8 | 3,5 | 60 | 72 | Holzma | LSB52003 | LSB52003R |
| 530 | 5,2 | 3,5 | 30 | 60 | Schelling | LSB53001 | LSB53001 |
| 530 | 5,8 | 4,0 | 60 | 60 | Anthon | LSB53002 | LSB53002 |
| 540 | 4,8 | 3,5 | 60 | 48 | Holzma Typ 33 | LSB54001 | LSB54001R |
| 540 | 4,8 | 3,5 | 60 | 60 | Holzma Typ 33 | LSB54002 | LSB54002R |
| 540 | 4,8 | 3,5 | 60 | 72 | Holzma Typ 33 | LSB54003 | LSB54003R |
| 550 | 5,2 | 3,5 | 60 | 48 | LSB55001 | LSB55001R | |
| 550 | 5,2 | 3,5 | 60 | 60 | LSB55002 | LSB55002R | |
| 550 | 5,5 | 3,8 | 40 | 48 | Schelling | LSB55003 | LSB55003R |
| 550 | 5,5 | 3,8 | 40 | 60 | Schelling | LSB55004 | LSB55004R |
| 550 | 5,2 | 3,5 | 80 | 48 | Gabbiani | LSB55005 | LSB55005R |
| 550 | 5,2 | 3,5 | 80 | 60 | Gabbiani | LSB55006 | LSB55006R |
| 565 | 5,2 | 3,5 | 80 | 48 | Gabbiani | LSB56503 | LSB56503R |
| 565 | 5,2 | 3,5 | 100 | 48 | Mantec* | LSB56501 | LSB56501R |
| 565 | 5,2 | 3,5 | 100 | 60 | Mantec* | LSB56502 | LSB56502R |
| 570 | 5,2 | 3,5 | 80 | 48 | Gabbiani | LSB57002 | LSB57002R |
| 570 | 4,8 | 3,5 | 60 | 60 | Holzma | LSB57001 | LSB57001R |
| 600 | 5,8 | 4,0 | 60 | 60 | Holzma Typ 33 | LSB60001 | LSB60001R |
| 600 | 5,8 | 4,0 | 60 | 72 | Holzma Typ 33 | LSB60002 | LSB60002R |
| 620 | 6,2 | 4,2 | 40 | 60 | Schelling | LSB62001 | LSB62001R |
| 620 | 6,2 | 4,2 | 40 | 72 | Schelling | LSB62002 | LSB62002R |
| 670 | 5,8 | 4,2 | 60 | 60 | Holzma | LSB67001 | LSB67001R |
| 670 | 5,8 | 4,2 | 60 | 72 | Holzma | LSB67002 | LSB67002R |
| 670 | 6,2 | 4,2 | 40 | 60 | Schelling | LSB67003 | LSB67003R |
| 670 | 6,2 | 4,2 | 40 | 72 | Schelling | LSB67004 | LSB67004R |
| 680 | 6,2 | 4,2 | 40 | 60 | Schelling | LSB68001 | LSB68001R |
| 700 | 7,0 | 5,0 | 80 | 60 | Anthon LNC | LSB70001 | LSB70001R |
| 720 | 6,4 | 4,4 | 40 | 60 | Schelling | LSB72001 | LSB72001R |
| 730 | 6,2 | 4,2 | 60 | 60 | Holzma Typ 66 | LSB73001 | LSB73001R |
